HZ7106B
Twin-Beam Explosion-Proof Searchlight
Two 12W spot beams and two 6W flood panels for maximum throw.
Ex db ia IIC T6 Gb
ExExplosion protected, built to the IEC 60079 standardsdbFlameproof enclosure: an internal ignition cannot escapeiaIntrinsically safe circuit, safe even with two faultsIICGas group IIC: hydrogen, acetylene and all IIA and IIB gasesT6Surface temperature never above 85 °CGbHigh protection, for Zone 1 and Zone 2- Light source
- 2 × 12W spot + 2 × 6W flood LED
- Battery
- 22.2 V, 2.5 Ah
- Runtime
- Spot high ≥5 h, work ≥10 h; flood high ≥8 / 4 h, work ≥16 / 8 h (one / both sides)
- Weight
- 1288 ± 5 g
Specifications
| Ex marking | Ex db ia IIC T6 Gb |
|---|---|
| Ingress protection | IP66 / IP68 (2 m, 1 h) |
| Light source | 2 × 12W spot + 2 × 6W flood LED |
| Battery | 22.2 V, 2.5 Ah |
| Runtime | Spot high ≥5 h, work ≥10 h; flood high ≥8 / 4 h, work ≥16 / 8 h (one / both sides) |
| Charging time | ≤6 h |
| Dimensions | Ø70 × 190 mm |
| Weight | 1288 ± 5 g |
Specifications are from the manufacturer's 2026 catalog. Confirm the exact configuration in your quote.
Features
- Twin spot beams
Used in
Private label options
Laser-engraved or printed logo, housing colour, gift box or carton printing, multilingual manual, charger plug type. How OEM works
Price and lead time for HZ7106B
Tell us the quantity and destination. We send unit prices, lead time and a copy of the certificate.
